Carton Box Sample Cutting Machine

Product Description

McLantis creasing and die cutting machines are special equipments for die cutting and creasing a wide range of materials, such as cardboard, corrugated board, plastic and leather.
McLantis creasing and die cutting machines are applicable to the fields of printing, packaging, decoration and plastic industries. The machines have been acceptable for the customers from home and abroad, due to their outstanding features, high quality and good service.

1. McLantis die cutting machine's sliding bearings are made of high quality alloy cooper, thus to get effect of anti-friction and shake reducing.
2. McLantis die cutting machine's flywheel is with big moment of force and large pressure.
3. High strength due to one piece casting by using top-ranking material for machine body.
4. Single plate electromagnetic clutch is sensitive and reliable.
5. With functions of single, continuous and opening dwell operation, dwell range is adjustable.
6. Operating position is reasonably arranged, moving-bed can be opened to its optimum.
7. Safety system is reliable.
8. Central lubrication system guarantees fine lubrication and reduce friction.

Model		Working area of platen(mm)	Working speed(strokes/min)	Max. length of cutting(m)	Overall size	Weight (kg)
DIECUT MAC	8CD	750×520	25±2	15	1780×1590×1450	1700
	10CD	930×670	23±2	25	1670×1670×1630	3000
	11CD	1100×800	20±2	30	1900×1780×1700	4500
	12CD	1200×830	18±2	32	2000×2000×2000	4500
	13CD	1300×920	18±2	38	1920×2140×1800	6500
	14CD	1400×1000	17±2	38	2010×2400×1930	7200
	15CD	1500×1080	17±2	40	2010×2480×1960	8500
	16CD	1600×1250	16±2	43	2170×2560×2230	11500
	17CD	1700×1400	16±2	50	2240×2800×2130	14200
	18CD	1800×1280	16±2	50	2180×2760×2250	14500
	18CD2	1800×1400	16±2	52	2240×2800×2130	15500
	20CD	2000×1400	16±2	58	2270×3100×2150	16500
	25CD	2500×1400	13±2	75	2300×3600×2150	19000
