Product Description

Fujian Yiyue Machinery Technology Co., Ltd. is a professional company specializing in the production of coated steel plate, wood grain steel plate, VCM steel plate, color steel plate, plastic plate and other series of products. The coated steel plate not only has the performance and advantages of ordinary color coated plate, but also greatly makes up for the lack of monotonous color of ordinary color coated plate. It has a variety of surface effects and colors. According to the patterns, it can be divided into wood grain, marble grain, granite grain, brick grain, imitation stainless steel wire drawing grain, camouflage and other products under research and development at present are: sheepskin grain, orange grain, refrigerator grain, concave and convex flower Lines, etc. Products are suitable for construction, furniture, door industry, transportation, home appliances, office and other industries!

The manufacturer of laminating iron production line said that laminating iron, through adhesion, will glue the plastic film and the steel sheet together. Coated iron, through the melting method, composite the color printed plastic film on the cold-rolled steel sheet, instead of printing on tinned iron and chrome plated iron with iron. There is a low temperature laminating iron production line in China, i.e. using sticking method. This process uses hot-melt glue melted at low temperature, which can't be boiled at the temperature above 120 ºC. It can only be used in biscuit cans, pet food cans and other industries with low requirements. It can't be used in beer cans, beverage cans, tomato sauce, asparagus, sweet corn cans and other products with higher requirements.

The manufacturer of laminating iron production line said that laminating iron, through adhesion, will glue the plastic film and the steel sheet together. Coated iron, through the melting method, composite the color printed plastic film on the cold-rolled steel sheet, instead of printing on tinned iron and chrome plated iron with iron. There is a low temperature laminating iron production line in China, i.e. using sticking method. This process uses hot-melt glue melted at low temperature, which can't be boiled at the temperature above 120 ºC. It can only be used in biscuit cans, pet food cans and other industries with low requirements. It can't be used in beer cans, beverage cans, tomato sauce, asparagus, sweet corn cans and other products with higher requirements.

Model	ZHHY-001
Basic Material Thickness	0.18-0.5mm
Specification	L18-20mW6.3mH3.4m
Input Power	380V-250KW-150KW
Vehicle Speed	0-60m/min
Equipment table size	≤1300mm(Coil Width:500-1150mm)
Vertical Laminating	Holt Melt Laminating Machine
	Lamination Machine
	Laminator
Product Process
Adopt plastic film (PET,PVC,PVDF,ASA) combined with metal plate through hot melting , which has solved the corrosivity of metal plate and metal container , both has the decorating , barrier of plastic film and the malleability ,figurability of metal sheet. Metal plate : galvanized sheet , stainless steel sheet , cold rolled sheet , aluminum sheet. Plastic Film: PET,PVC,PVCF,ASA etc. Film Color: RAL color/Pantone color; wood grain , marble grain , brick grain , stone grain , flower pattern , brushed , embossed.
